Research & Development

Yezhan Electronics has cutting - edge R & D capabilities, with 20 - million - yuan worth of equipment. It meets diverse inspection needs for alloy resistor products from microscopic to macroscopic.

7 - year raw material system research

Passive components' performance depends on material science. Yezhan Electronics' tech approach is based on alloy raw material processing.
An R & D team of materials science postdocs and grad students updates smelting formulas, adjusting trace element ratios to meet industry needs.

12 - year research on heat treatment wire drawing & rolling process

Hot silver treatment, cold rolling, and heat treatment achieve alloy material pre - treatment, ensuring excellent consistency, stability, and controllable TCR.
Yezhen can offer ultra - low TCR solutions for most products compared to industry standards.

15 - year research on welding technology

Automatic fluorine arc welding tech (Patent No.: ZL202120857626.X) enables 100+ HSR series specs, replacing British TT's OAR series products.
Automatic resistance welding tech (Patent No.: ZL202020620880.3) enables 100 - spec JSR series production, auto test & adjust, cuts costs, increases production.
The automatic laser welding tech (Patent No.: ZL201820907052.0) pioneered welding 0.1 - 0.4mm thick copper strips.
Yezhan used auto electron beam welding tech to expand thickness from 1 - 4mm to 0.3 - 4mm after 10+ years of tech & process accumulation.
Welding tech breakthroughs enabled resistors to cover all sizes, achieve international brand substitution domestically.

17 - year study on alloy resistor structure

Research on current distribution & resistor structure impacts on product temperature drift.
Resistor structure and pattern optimization.
Resistor structure & thermal simulation design.
17 - year alloy resistor experience.
7 year
raw material system research
12 year
research on heat treatment wire drawing & rolling process
15 year
research on welding technology
17 year
study on alloy resistor structure

Yezhan team consists of young people under 35, full of vitality and innovation. We're helping world-class companies boost product competitiveness in design.

IN 2005
YSR/TSR jumper type Resistance value: 0 - 1000mΩ Span: 5 - 30mm
IN 2007
HSR soldering-foot type Resistance value: 3 - 150mΩ Span: 5 - 30mm JSR zigzag type Resistance value: 3 - 100mΩ Span: 10 - 35mm CSR press-foot type Resistance value: 0 - 50mΩ Span: 5 - 30mm
IN 2009
ISO9001
IN 2011
ASR-M/K Dimensions: 2512/3920/5930 Resistance value: 0.1 - 5mΩ Power: 3 - 15W
IN 2012
FHR Dimensions: 8420/8518 Resistance value: 0.035 - 0.5mΩ
IN 2015
YLR Dimensions: 1206 - 4527 Resistance value: 0.1 - 200mΩ SBB Four-Terminal Dimensions: 1216/2726/4026 Resistance value: 0.2 - 0.5mΩ FHR-M/K Dimensions: Customized Resistance value: 0.02 - 0.5mΩ
IN 2016
ASH Dimensions: 1206/2010 Resistance value: 0.3 - 6mΩ ASR Dimensions: 1206 AEC-Q200
IN 2017
YLRP Dimensions: 2512/2817/2728/3637 Resistance value: 2 - 200mΩ Temperature drift: ±10 - ±30ppm
IN 2019
IATF 16949
IN 2020
ASHP Dimensions: 2512/3920 Resistance value: 1 - 5mΩ Temperature drift: ±10/±20ppm FHRP Dimensions: 1625/2025/2530 Resistance value: 0.1/0.2/0.3mΩ SBBP Four - Terminal Dimensions: 2726/4026 Resistance value: 0.2 - 0.5mΩ Temperature drift: ±20/±40ppm YLRP Temperature drift: ±5ppm YSK Four - Terminal Surface - Mount Dimensions: 0402/0612/1225 Resistance value: 0.15 - 3mΩ
IN 2021
Four - terminal Leads Dimensions: 2321/3825/4618 Temperature Drift: ±5 - ±30ppm
IN 2022
New Product Development ULR: Ultra - High - Power Metal Foil Resistor HSM: Electric Vehicle Shunt
